05/05872-00
HD SOLDER-TYPE FEMALE D-SUB CONNECTORS
CONN.SUBM.FEMM.VASCH. A. DENS.26P
Guarda i prodotti della stessa famiglia
High density D-SUB connector
Details
WORK. VOLT.:300 V
MAX CURRENT:3 A
WORK. TEMP.:-20°C - +80°C
CONTACTS:copper
INSULATION:polyester
COVERS:05/06600
SPACER:05/06700
TURRETS:05/06705
FOR CONNECT.:05/05890
More Information
| Unit of measure | Pieces |
|---|---|
| Number of poles | 26 |
| Dimension B | 26,0 mm |
| Dimension A | 39,1 mm |
| Dimension C | 33,3 mm |
| Dimension E | 12,5 mm |
| Dimension D | 9,1 mm |
